Bending tools, press brake tooling for Beyeler - Bystronic System

We offer for our customers all bending tooling solutions for hydraulic and electric press brakes for clamping system Beyeler - Bystronic for systems Beyeler-S (old system), Bystronic R, Bystronic RFA. We supply: punches, dies, adapters with rich selection of standard types and possility to make any special tools under request of customer including the length of 6000-8000 mm in one piece.
Please note: Bystronic machines could be equipped also with Promecam Euro clamping system.
We are able to assist the customer to recommend tools according to his parts as well as to prepare the sequence or quotation for special shapes if necessary.
Standard Beyeler - Bystronic dies are interchangeable with Trumpf system or Wila system die clamping system so it is possible to use H100 dies if necessary.

Sizes and sets:

• Solid pieces 100, 500 mm
• Solid pieces 1000 mm (for dies only)
• 550 mm segmented set for punches. Segmented set includes pieces: 100 horn left, 20, 25, 30, 35, 40, 200, 100 horn right
• 550 mm segmented set for dies. Segmented set includes pieces: 200, 25, 25, 30, 35, 40, 100, 100 mm
• 1100 mm segmented set for dies. Segmented set includes pieces: 10, 15, 20, 30, 40, 50, 60, 75, 100, 100, 200, 400 mm
